MTP - LC Multi Cord Mpo Duplex Fiber Optic Patch Cord OM1 -OM4 With Ceramic Ferrule

: Large Image : MTP - LC Multi Cord Mpo Duplex Fiber Optic Patch Cord OM1 -OM4 With Ceramic Ferrule

Product Details:

Place of Origin:	SHENZHEN,CHINA
Brand Name:	J&K
Certification:	IS09001-2008.ROHS
Model Number:	MPO Patch cord

Payment & Shipping Terms:

Minimum Order Quantity:	50PCS
Price:	Negotiation
Packaging Details:	PE bag
Delivery Time:	3~5days
Payment Terms:	L/C, T/T

Contact Now

Detailed Product Description

Application:	FTTH FTTB FTTX Network	Cable Jacket:	PVC/LSZH/Plenum
Operating Temperature:	-20℃~+70℃	Name:	Fiber Optic MPO Patchcord
Storage Temperature:	-40℃~+85℃	Durability (500 Matings):	≤0.2dB
Highlight:	mpo mtp patch cord , duplex fiber optic patch cord

OM1 OM2 OM3 OM4 multi cord cable jumpers fiber optic MPO patch cord

Features

Ceramic Ferrule;
High return loss;
Low insertion loss;
Good repeat-ability and and ex-changeability;
Excellent Polished and 100% tested;
Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard.

Applications

Local Area Network (LAN)
Data communication network
Telecommunication optical transmission network
Optical access network(OAN)
Active device termination
Fiber optics data transmission(FODT)

Specifications

Parameter
Model		Singlemode	Multimode
Polish		PC, APC	PC
Insertion loss	Standard	≤0.7dB	≤0.6dB
	Elite low loss	≤0.35dB	≤0.35dB
Return loss		PC≥50dB; APC≥60dB	≥30dB
Test wavelength		1310/1550nm	850/1310nm
Durability (500 Matings)		≤0.2dB
Operating temperature		-20℃~+70℃
Storage temperature		-40℃~+85℃
Fire resistant		IEC 60794-2-30
Fiber type		OS2, OM1, OM2, OM3, OM4
Cord type		8, 12, 24, 48, 72, 96, 144 cores
Cable diameter		3.0mm (8 or 12 or 24 core), 5.5(24core), or customized
Cable jacket		LSZH, OFNR, OFNP
Length(M)		0.3m, 1m, 2m, 5m, 10m, 25m, 50m, 100m
