0.9mm Fiber Optic Cable Lc Connector ,Nickel Plated Brass Lc Duplex Fiber Connector

Large Image : 0.9mm Fiber Optic Cable Lc Connector ,Nickel Plated Brass Lc Duplex Fiber Connector

Product Details:

Place of Origin:	SHENZHEN,CHINA
Brand Name:	J&K
Certification:	ISO9001:2008
Model Number:	DIN SM SX Connector

Payment & Shipping Terms:

Minimum Order Quantity:	1000PCS
Price:	Negotiation
Packaging Details:	PE bag
Delivery Time:	3~5days
Payment Terms:	L/C, T/T

Contact Now

Detailed Product Description

Product Name:	Fiber Optic SC Connector	Application:	FTTH FTTB FTTX Network
Insert Loss:	SM≤0.2dB,MM≤0.25dB	Return Loss:	PC≥50dB,UPC≥55dB,APC≥65dB
Operating Temperature:	-40°C ~ +80°C	Durability:	<0.2db Typical Change
Highlight:	quick connect fiber optic connectors , terminate fiber lc connector

Fiber Optic Simplex Singlemode DIN Connector with Nickel Plated Brass

Features

High quality ceramic components and Material
End-face geometry requirement complies to Telcordia GR-326-CORE
100% tested on optical performance (Insertion Loss & Return Loss)
Simplex, duplex and higher core densities

Applications

Cable Standard Boot (slotted)
Fiber Buffer Boot
Fiber Boot
Cable Short Boot
Cable Long Boot (Telcordia type)
Fiber Buffer Long Boot (slotted)

Specifications

DIN fiber optical connector	Single mode	Multimode
Insertion Loss	≤0.20dB	≤0.25dB
	≥50 dB (PC)
Return Loss	≥55 dB (UPC)
Durability	≥65 dB (APC)
Operating Temperature	<0.20 dB typical change	1000 mating -40 to + 80°C
	125.0+1/-0μm, Concentricity: ≤1.0μm	125μm, Concentricity:≤3μm
Ferrule Hole Sizes	125.5+1/-0μm, Concentricity: ≤1.0μm	144μm, Concentricity: ≤3.0μm
