DIN Single Mode Fiber Lc Connector , Circular Fiber Optic Quick Connector For FTTH Network

: Large Image : DIN Single Mode Fiber Lc Connector , Circular Fiber Optic Quick Connector For FTTH Network

Product Details:

Place of Origin:	SHENZHEN,CHINA
Brand Name:	J&K
Certification:	ISO9001:2015
Model Number:	DIN SM Fiber Optic Connector

Payment & Shipping Terms:

Minimum Order Quantity:	1000PCS
Price:	Negotiation
Packaging Details:	PE bag
Delivery Time:	3~5days
Payment Terms:	L/C, T/T

Contact Now

Detailed Product Description

Product Name:	Fiber Optic Connector	Application:	FTTH FTTB FTTX Network
Durability:	≤ 0.2db Typical Change	Operating Temperature:	-20~70℃
Storage Temperature:	-40~85℃	Return Loss:	UPC≥50.0dB,APC≥60.0dB
Highlight:	quick connect fiber optic connectors , terminate fiber lc connector

DIN singlemode Fiber Optic Connector for FTTH Network

Features

Corrosion resistant body
Boots in a variety of colors
Free-floating ceramic ferrule
Low insertion loss and back reflection loss

Applications

Local Area Networks (LANs)
Data processing networks
Test equipment
Premise installations
Wide Area Networks (WANs)

Specifications

ITEM	PARAMETER
Applicative Connector Type	SC,LC,FC,ST,MU,D4,DIN
Fiber mode	Single mode	Multi-mode
Test wavelength	1310nm, 1550nm	850nm, 1300nm
Insertion Loss	typical≤0.20dB,Max≤0.30dB	typical≤0.15dB,Max≤0.25dB
Return Loss	UPC≥50.0dB,APC≥60.0dB	≥35.0dB
Durability	≤0.20dB typical change,1000 mating
Applicative cable OD.	∮0.9mm/∮1.8mm&∮2.0mm /∮3.0mm (MU only ∮0.9mm/∮2.0mm)
Connector Ferrule OD.	∮2.5mm:SC, FC,ST,DIN; ∮2.0mm:D4; ∮1.25mm:LC,MU
Angle BOOT	SC,LC(45 or 90 degree)
Operating Temperature	-20ºC to +70ºC
Storage Temperature	- 40ºC to +85ºC
Ferrule Specification	125.3+1/-0μm, Concentricity: ≤1.0μm	127+3/-0μm, Concentricity: ≤3.0μm
