Product Details:
Payment & Shipping Terms:
|
| Model Number: | 1×2 PLC Splitter | Wavelength: | 1260-1650nm |
|---|---|---|---|
| Insertion Loss: | <=4.0dB | Directivity: | ≥55dB |
| Channel Uniformity: | <=0.6dB | Polarization Dependent Loss:: | <=0.2dB |
| Highlight: | active optical splitter,fiber optic coupler splitter |
||
Fiber optic LC splitter is an optical power device based on quartz plate planar of light wave technology, which is widely used in local side or termination of Passive Optical Network (EPON, BPON, GPON etc.) for splitting of optical signal. It offers superior optical performance, high stability and high reliability; meet various application requirements in different environments.
1. Features:
1. 1xN and 2xN splitters tailored per application
2. Low Insertion Loss and low PDL
3. Superior Uniformity
4. Wide Operation Wavelength
5. Wide Operation Temperature
6. High Stability and Reliability
7.Telcordia GR-1209 and GR-1221 Compliance
8. YD/T 2000.1-2009 Compliance (TLC Product Certificate Compliance)
2. Applications:
Optic communication system
LAN
CATV
Test instrument
Fiber optic sensor
3. Specification:
|
Grade Parameter |
Grade“Premium” | |||||
| Operating Wavelength (nm) | 1310&1550nm,others on request | |||||
| Bandwidth (nm) | ±40nm | |||||
| Excess Loss (dB) | ≤0.1dB(0.06dB TYP ) | |||||
| Coupling Ratio (%) | 50/50 | 40/60 | 30/70 | 20/80 | ||
| Typ. Insertion Loss (dB) | 3.1 | 4.2/2.4 | 5.4/1.7 | 7.2/1.1 | ||
| Max. Insertion Loss (dB) | 3.4 | 4.5/2.7 | 5.8/2.0 | 7.6/1.5 | ||
| Polarization Dependent Loss (dB) | 0.1 | 0.1 | 0.15/0.1 | 0.15/0.1 | ||
| Thermal Stability (dB /℃) | ≤0.2dB | |||||
| Directivity (dB) | ≥55 dB(≥60dB 2×2) | |||||
| Operating Temperature(℃) | -20℃to +70℃ | |||||
| Package Type | 1.bare fiber1:900um loose tube；2.Φ0.9& tube Φ3.0tube:900um loose tube or3mm loose cable (or 2mm)；3Pigtail Type l4.19″Standard rack type | |||||
| Lead length | 1 meter, others on request | |||||
| Package Dimensions(mm) | Φ3×54 | 90×20×10 | 100×80×10 | |||
